Description
Mark parking and reverse more easy and safe, also protect your car.
1 Measure/sense the accurate distance between the obstacles and the back of the car.
2 When the back of car is very close to the obstacles, there will be buzzer to warn the driving.
3 The alarm sounds also warn the walkers to take care.
Features & Functions:
1,Numeral and color LED display
2,Alarm by three-step Bibi sound
3,Left and right obstacle indication
4,Numeral display from 2.0m to 0m
Parameter:
|
voltage |
9DCV—15DCV |
|
Rated voltage |
12DCV |
|
Power cost |
Max 0.5W |
|
Respond distance |
0.3m—2.0m |
|
Alarm distance |
0m—2.0m |
|
Display mode |
Led display |
|
Sensor diameter |
22mm |
|
Install mode |
drill |
|
Sensor angle |
X,Y,60℃ |
|
work temperature |
-30℃—+80℃ |
|
Alarm type |
Buzzer (Bi Bi….) |
|
alarm volume |
65dB |
|
Alarm frequency |
1.6-2.0m:0.5 HZ(slowness);;1.1-1.5m :1 HZ(slowness); 0.6-1.0m:3 HZ(commonly); 0-0.4m :BI—– ; |
Specifications:
1. Wireless connection between control box and display
2. Automatically working when reversing
3. Alarm by three-step bibi sound
4. Display the distance and direction of obstacles on the screen
5. All models are available for wireless connect .
6. Four sensors
Packing: color box
Carton Size: 52.5*26*33cm
Qty/Carton: 10pcs
G.W/N.W: 10/9.5KGS
