Description
description:
4 Channel 8 Channel AHD DVR Surveillance Security CCTV Recorder DVR 4CH 720P / 8CH 1080N Hybrid DVR For Analog AHD IP
Features
Support AHD-M series front-end real-time encoding;
Support VGA, HDMI HD output;
Support XM Cloud technology, easy to achieve a variety of network penetration, one step to remote monitoring, getting rid of various complicated network settings, easy and simple to operate;
Support various mobile monitoring:(IOS, Android).
Support multiple web browsers(IE,Chrome,Firefox,Safari);
Support more than 20 languages(English, Finnish, French, German, Greek, Italian, Japanese, Polish, Portuguese, Russian, Spanish, Thai, Chinese, Traditional Chinese, Turkish, etc.), no nation boundaries;
perfect protection circuit, unique triple watchdog function
Supporting web, CMS, center platform management software MYEYE, provide SDK development.
4CH AHD-DVR Specification
| Model | A1004NS | |
| System | Main processor | Huawei Hi 3520D |
| Video | video compression | H.264(High Profile); |
| Encode | 4*AHD-M/4*AHDNH | |
| Decode | 1*AHD-M/1*AHDNH | |
| Multi-mode
input |
Pure AHD:4*AHDNH;4*AHD-M
Pure IP : 4*1080P;8*960P Mixed : 2*AHDM+2*720P |
|
| Audio | Audio compression | G.711A |
| Intercom | support | |
| Recording and Playback | Record mode | Manual>alarm>motion detection>timing |
| Playback Channels | 4 (pure local input mode) | |
| Storage and backup | Space occupation | 960H:12~20G/ day*channel
720P:20G/ day*channel audio:691.2M/ day*channel |
| Backup mode | Network backup/USB HDD/ USB writer/SATA writer | |
| Interface | Video input | 4 BNC |
| Video output | 1ch VGA,1ch HDMI | |
| Audio input | 1CH RAC | |
| Audio output | 1CH RAC | |
| Alarm input | No | |
| Alarm output | No | |
| Network interface | RJ45 10M/100M Adaptive Ethernet port | |
| PTZ control | Have NO RS485 ;Don’t support PTZ function | |
| USB | 2 USB ports | |
| Hard disk | 1 SATA(Each maximum support 4T ) | |
| Wireless | null | |
| Other | Power | 12V/2A |
| dimension | 255mm(length)* 225mm(width)* 45mm(height) |
8CH AHD DVR Specification
8CH is 5 in 1 Version which supports TVI CVI AHD IP and Hybrid Mode !
| Model | A1008NHS | |
| System | Main processor | Huawei Hi 3520 |
| Video | video compression | H.264(High Profile); |
| Encode | 8*AHD-NH | |
| Decode | 8*AHD-NH | |
| Multi-mode
input |
Pure Analog:8*AHDNH; 4*AHDNH;
Mixed:4*AHDNH+4*960P(Network); Pure Network:16*1080P; 4*5Mb |
|
| Audio | Audio compression | G.711A |
| Intercom | support | |
| Recording and Playback | Record mode | Manual>alarm>motion detection>timing |
| Playback Channels | 4 (pure local input mode) | |
| Storage and backup | Space occupation | 960H:12~20G/ day*channel
720P:20G~30G/ day*channel audio:691.2M/ day*channel |
| Backup mode | Network backup/USB HDD/USB writer/SATA writer | |
| Interface | Video input | 8 BNC |
| Video output | 1ch VGA,1ch HDMI | |
| Audio input | 1CH RAC | |
| Audio output | 1CH RAC | |
| Alarm input | No | |
| Alarm output | No | |
| Network interface | RJ45 10M/100M Adaptive Ethernet port | |
| PTZ control | Have no RS485 ;Don’t support multiple PTZ protocols | |
| USB | 2 USB ports | |
| Hard disk | 1 SATA(Each maximum support 4T) | |
| Wireless | null | |
| Other | Power | 12V/2A |
| dimension | 255mm(length)* 225mm(width)* 45mm(height) |
Package Content
1*4CH/8CH AHD DVR HVR
1*Mouse
1*Power Supply 12V 2A ( US/EU Optional ) For AHD DVR
1-Software and usermanual
Note :HDD IS NOT INCLUDED!!
4CH AHD DVR：
8CH AHD DVR：
4CH AHD DVR：
8CH AHD DVR：
