Description:
This Colorful H81M-K PLUS V23B motherboard is based on Intel H81 chipset which supports Intel LGA1150 Haswell processors. It comes with 2 memory slots which support DDR3 dual channel DDR3 1333/1600MHz memory. It is equipped with high quality PCB plate to bring long lasting durability and ultra stable performance.
Specification:
Motherboard series: Intel chipset, COLORFUL series
Chipset: Intel H81
Processor: Support Intel LGA1150 Haswell processors
Memory: 2 DIMM slots, support DDR3 dual channel 1333/1600MHz memory
Graphics support: 1*PCI Express2.0X16 slot
SATA ports: 2*SATA2.0, 2*SATA3.0 ports
Expansion slots: 1*PCI Express X1 slot
Output ports: VGA+HDMI
Power management: Support 84W processors
Hardware monitor: CPU Fan speed Controlled, SYSTEM Fan speed Monitoring, CPU Temperature Monitoring, System Temperature Monitoring, and Voltage monitoring
LAN: Realtek RTL8111F 1000M LAN
Audio: ALC662 6-channel audio chipset
I/O chip: NCT5532D
Other features: Support ACPI S1/S4/S5
PCB size: 215*170mm mATX
Item weight: Approx. 360g /12.7oz
Package size: 27 * 26 * 5.8cm /10.63 * 10.24 * 2.28in(L * W * H)
Package weight: 700g /24.69oz
Memory Slots
SATA Ports
Two SATA3.0 ports increase the data transfer rate between the motherboard and internal storage devices.
Realtek ALC662 6-channel audio chipset prevents the noise disturbance of high-frequency signal from the complex circuit.
High quality PCB plate ensures a longer service life and boost the ultimate performance.
